AWI Industries Laser Modules
AWI Industries Laser Modules AWI Industries Laser Modules
AWI Industries Laser Modules AWI Industries Laser Modules



AWI Industries Laser Modules



Part No. Output Power Wavelength Operating Current Operating Voltage Spot size at 5m Operating Temperature Range Working Distance (day time) Working Distance (night time)
Red (mW) (nm) (mA) (VDC) (mm) (deg C) (m) (m)
E10531-A-511 <1 650 50 4.5 9 -10 to 40 150 300
E10531-A-515 <5 650 50 4.5 9 -10 to 40 150 300
E10531-A-311 <1 635 50 4.5 9 -10 to 40 450 900
E10531-A-315 <5 635 50 4.5 9 -10 to 40 450 900
E10531-B-511 <1 650 50 3.0 9 -10 to 40 150 300
E10531-B-515 <5 650 50 3.0 9 -10 to 40 150 300
E10531-B-311 <1 635 50 3.0 9 -10 to 40 450 900
E10531-B-315 <5 635 50 3.0 9 -10 to 40 450 900
E10531-C-581 <1 650 50 3.0 9 -10 to 40 150 300
E10531-C-585 <5 650 50 3.0 9 -10 to 40 150 300
E10531-C-381 <1 635 50 3.0 9 -10 to 40 450 900
E10531-C-385 <5 635 50 3.0 9 -10 to 40 450 900
E10531-D-561 <1 650 50 3.0 9 -10 to 40 150 300
E10531-D-565 <5 650 50 3.0 9 -10 to 40 150 300
E10531-D-361 <1 635 50 3.0 9 -10 to 40 450 900
E10531-D-365 <5 635 50 3.0 9 -10 to 40 450 900
Green (mW) (nm) (mA) (VDC) (mm) (deg C) (m) (m)
E10531-G-655 <5 532 <350 3.0 8 20 to 30 500 1000
